Incredible strength. In compact form.
The DL600 dump trailer from Stronga delivers truly unbeatable value for money.
The DL600 tipper trailer is specifically conceived for use by professional contractors on small-to-medium size construction projects. What the DL600 model lacks in size, compared to other models in the range, it makes up for in incredible manoeuvrability, exceptional reliability and the highest performance.
Small → medium construction projects
Compact with mighty strength
Full Hardox body
With a design developed through multiple decades
You need a reliable trailer.
You need a construction-site trailer that makes your life simple – that gets the job done, performs in tough conditions, and is easily maintained. That’s what our legacy of building tipper trailers has taught us; and it’s a future we’ll continue to pioneer with every new DL600 trailer.
Take the lead, while others follow
Stronga dump trailer for sale, delivering Stronga’s values with market-leading features:
(1) Ultra-low chassis enables the comfort of a stable ride with improved cornering in tight spaces.
(2) Minimal under-floor supports with ultra-light, extra-strong Hardox 450 wear plate.
(3) 65° tipping angle accelerates deposition while making efficient use of storage space.
(4) Low profile tyres minimises height, improving the ease in which plant is loaded.
(5) Pin & cup system allows quick and easy removal of the rear door to transport plant.
Standard Specifications
Optional Equipment
STR-215
BPW commercial axle, 410x120 brake axles, 120x120mm square beam, 10 stud.
STR-302
Load sensing for hydraulic brakes.
STR-303
WABCO air brakes on all wheels of the tipper trailer.
STR-304
Load Sensing Valve (LSV) for air brakes.
STR-305
Dual air and hydraulic brake system.
STR-307
Automatic slack adjusters.
STR-501
Multi-position sprung drawbar for high comfort at speed.
STR-505
Bolted-on ball towing hitch, Scharmuller type, 80mm diameter.
STR-506
Swivel towing hitch, Scharmuller type. 50mm diameter eyelet.
STR-902
2 x rear rubber mud-flaps.
STR-903
Hard plastic quarter mudguards, front and rear of the tipper trailer.
STR-1001
Aluminium, heavy-duty side protection rails.
STR-1005
Multi-position removable round bumper at the rear of the tipper trailer.
STR-1037
Two super-bright LED rear working lights.
STR-1002
Rear towing eyelet mounting plate for VBG rear drawbar.
STR-1038
Rear mounted hydraulic brake connection.
STR-1039
Rear mounted light connection 7-pin socket.
| Model | DumpLoada DL600 |
|---|---|
| Gross weight | 18000kg |
| Tare weight | ca. 3500kg |
| Maximum Payload | 14500kg |
| Drawbar load | 3000kg (4000kg*) |
| Sprung suspension capacity | 14000kg |
| Standard transport capacity | 6m³ |
| Lift capacity of step 1 at 180 bar | 29,7 tonnes |
| Oil requirement | 15,5 litres |
| Minimum draft requirement | 100HP |
| Hitch height | 510-550-590mm |
| Bottom tickness | 6mm HARDOX 450 |
| Side tickness | 6mm HARDOX 450 |
| Body height inside | 600mm |
| Body length inside | 4060mm |
| Total length | 5605mm |
| Total height | 1785mm |
| Total height at 65" | - |
| Maximum width (standard wheels) | 2550mm |
| Standard wheels | 445/40 R22,5 |
| Colour | Yellow |
| Speed | 40km/h |
All weights and measurements are subject to tipper trailer specification and regional laws. Specification, weights and payload may vary on fast tow models. As we are continually improving our products, technical details, masses and measurements are given as reference values only.
