DumpLoada DL1000

Mid-range model. 100% more capacity compared to DL600.

Count on a strong tipper trailer

24t hydraulic dump trailer designed for hauling construction materials and excavated earth and rocks. Low cost of ownership and superior ergonomics explain why DL1000 is proving popular for medium-size construction projects. Heavy duty, damage-resistant chassis and full Hardox 450 body help DL1000 withstand everything thrown at it. Strength, lightness and reliability are maximised at all times.

Scandinavian construction site video >

Heavy-duty, wear resistant tipper trailer

The tipper trailer body is built entirely of Hardox 450 wear-resistant, high-tensile plates with a rigid square body design to increase structural strength. 6mm abrasion-resistant Hardox 450 side walls and 8mm Hardox 450 base plates of the dump section are reinforced with ribs for added strength and durability.

#StrongaInScandinavia

Stronga are proud to continue a formidable alliance with successful Norwegian contractors, Tractor & Gravemaskindrift A/S. T&G use their fleet of DL1000 and DL1200 tipper trailers to deliver infrastructural projects throughout Norway, completing them on-time and to the highest standards.

Standard Specifications

BPW commercial axle, 410x120 brake axles, 120x120mm square beam, 10 stud.
21t multileaf sprung suspension. 1480mm distance between axles.
Multi-position sprung drawbar for high comfort at speed.
Powerful hydraulic brakes on all wheels.
445/65 R22,5 radial tyres. Load rating per tyre:
7000 kg @ 105 km/h
Hard plastic quarter mudguards, front and rear of the tipper trailer.
2 x rubber mud-flaps.
Multi-position removable round bumper for rear protection of the tipper trailer.
Single top-hung rear door with hydraulic flip back.
Brackets with lock for the rear door in the front of the box.
3 position plate for bolting towing eyelet.
Swivel towing hitch. STR type. 50mm diameter eyelet.
HARDOX 450 steel. 8mm tipper trailer floor. 6mm dump trailer sides.
12 V electric system. Sealed loom. All lights super-bright LED.
Cable-type hand brake.
Suspended drawbar shoe with stowage point.

Optional Equipment

STR-210


BPW commercial axle, 410x180 brake axles, 150x150mm square beam, 10 stud.

STR-302


Load sensing for hydraulic brakes.

STR-303


WABCO air brakes on all dump trailer wheels.

STR-304


Load Sensing Valve (LSV) for air brakes.

STR-305


Dual air and hydraulic brake system.

STR-307


Automatic slack adjusters.

STR-308


Load Sensing Valve (LSV) for hydraulic suspension.

STR-505


Bolted-on ball towing hitch, Scharmuller type, 80mm diameter.

STR-506


Swivel towing hitch, Scharmuller type. 50mm diameter eyelet.

STR-409


Air suspension with height controlling valve.

STR-410


Hydraulic suspension for optimum axle travel. Watch video >

STR-411


Front lift axle - Only with air or tipper trailer suspensions. Watch video >

STR-508


Hydraulic drawbar for easy tipper trailer levelling and high comfort. Watch video >

STR-707


Electronic Power Steering (EPS) for excellent efficiency and safety. Watch video >

STR-802


Other tyre brands and tyre sizes available.
Contact us for more information >

STR-1000


Lockable steel toolbox. Various sizes available.
Contact us for more information >

STR-1001


Aluminium tipper trailer side protection rails.

STR-1037


Two super-bright LED rear working lights.

STR-1002


Rear towing eyelet mounting plate for VBG rear drawbar.

STR-1038


Rear mounted hydraulic brake connection.

STR-1039


Rear mounted light connection 7-pin socket.
Model DumpLoada DL1000
Gross weight 24000kg
Tare weight ca. 5000kg
Maximum Payload 19000kg
Drawbar load 3500kg (4000kg*)
Sprung suspension capacity 21000kg
Standard transport capacity 12m³
Lift capacity of step 1 at 180 bar 38,4 tonnes
Oil requirement 29,4 litres
Minimum draft requirement 125HP
Hitch height 510-550-590mm
Bottom tickness 8mm HARDOX 450
Side tickness 6mm HARDOX 450
Body height inside 1000mm
Body length inside 5110mm
Total length 6750mm
Total height 2450mm
Total height at 65" 6400mm
Maximum width (standard wheels) 2550mm
Standard wheels 445/65 R22,5
Colour Yellow
Speed 40km/h

All weights and measurements are subject to tipper trailer specification and regional laws. Specification, weights and payload may vary on fast tow models. As we are continually improving our products, technical details, masses and measurements are given as reference values only.
