HookLoada HL180ST

Welcome to the cross-sector world of HookLoada.

Multi-modal world of HookLoada

HL180ST is the most popular entry point into the multi-modal world of HookLoada. With a 30% bigger payload than HL014S, the 18 tonne HookLoada is perfect for medium-size contractors who need extra capacity for only a small extra investment. Stronga’s classic 18 tonne HookLoada delivers reliability and performance like no other; leading the market with a stronger, lighter and lower design; enabling greater payload at speed.

Pretty. Epic.

Perfect cross-sector hybrid

HookLoada HL180ST continues to prove our most popular hooklift with huge numbers of satisfied users across the globe. Clients typically extend the use of this versatile hook lift system across a wide range of sectors from agriculture to waste management and construction. For clients with modern diversified businesses straddling different sectors, the 18 tonne Stronga hook lift system is the perfect cross-sector hybrid.



Key Benefits

Roller height on standard wheels – 1100mm



  • Stable cornering profile
  • Low container loading angle

Excellent tipping angle - 52°



  • Great heaping ability
  • Clean emptying across all materials

Hook container length - 4700 - 6000mm. Maximum hook container length - 6700mm



  • Access to the main, standard container market

Length from tower to rear roller - 5320mm



  • Compact while offering good capacity
  • Cross over to the ISO / intermodal world

Standard Specifications

BPW commercial 410×120 brake axles, 120×120 square beam. 10 stud.
21t multileaf sprung suspension. 1480mm distance between axles.
Shockproof rubber-mount drawbar for high comfort at speed.
Powerful hydraulic brakes on all wheels.
560/45 R22,5 Nokian Country King TL radial tyres. 10 stud heavy-duty wheels. Load rating per tyre:

6300kg @ 40km/h4625kg @ 65km/h
Hydraulic container locking clamps.
Hydraulic rear axle stabilisers.
3 position plate for bolting towing eyelet.
Swivel towing hitch. STR type. 50mm diameter eyelet.
Rear removable bumper.
12 V electric system. Sealed loom. All lights super-bright LED.
Cable-type hand brake.
Manual telescopic drawbar support leg.

Optional Equipment

STR-210


BPW high speed commercial axle, 410x180 brake axles, 150x150 - 16mm square beam, 10 stud.

STR-211


BPW auto-centring free steering rear axle, 420x180 brake axles, 150x150 - 16mm square beam, 10 stud, 2150mm track.

STR-214


CommandSteer™ - in-cab control – excellent manoeuvrability in reverse – free steering travelling forwards. Watch video >

STR-302


Load sensing for hydraulic brakes.

STR-303


WABCO air brakes on all wheels of the hook lift system.

STR-304


Load Sensing Valve (LSV) for air brakes.

STR-305


Dual air and hydraulic brake system.

STR-308


Load Sensing Valve (LSV) for hydraulic suspension.

STR-406


24t parabolic sprung suspension, 1810mm distance between axles.

STR-407


32t parabolic sprung suspension, 1810mm distance between axles.

STR-409


Air suspension with height controlling valve (AirLoada™ comes as standard when you buy STR-409). Watch video >

STR-410


Hydraulic suspension for optimal hook loader axle travel. Watch video >

STR-508


Hydraulic drawbar for easy levelling and high comfort. Watch video >

STR-707


Electronic Power Steering (EPS). Watch video >

STR-704


Independent hydraulic system with PTO, 130 l/min pump. Distributor operated by remote control.

STR-705


Two pipes to the tractor hydraulic system with distributor operated by remote control.

STR-700


Auxiliary hydraulic connections with changeover valve at the rear of the hooklift.

STR-723


Auxiliary hydraulic connections with electrical changeover valve at the rear of the hook lift system.

STR-710


Auxiliary connections with changeover valve on the hook tower.

STR-724


Auxiliary connections with electrical changeover valve on the hook tower.

STR-713


QuickLoada™ fast tipping and unloading system. Watch video >

STR-1037


Two super-bright LED adjustable rear working lights.

STR-802


Other tyre brands and tyre sizes available.
Contact us for more information >

STR-900


Full length ultra-light aluminium mudguards.

STR-903


Hard plastic quarter mudguards, front and rear of the hook lift system.

STR-1000


Lockable steel toolbox. Various sizes available.
Contact us for more information >

STR-1001


Aluminium side protection rails.

STR-505


Bolted-on ball towing hitch, Scharmuller type, 80mm diameter.

STR-506


Swivel towing hitch, Scharmuller type. 50mm diameter eyelet.

STR-1002


Rear towing eyelet mounting plate for VBG rear drawbar.

STR-1038


Rear mounted hydraulic brake connection.

STR-1039


Rear mounted light connection 7-pin socket.
Model HookLoada HL180ST
Gross weight (40km/h) 22000kg
Tare weight ca. 4900kg
Maximum hooking load 18000kg
Maximum tipping load 18000kg
Drawbar load 3500kg (4000kg*)
Hook height 1450mm
Hook tower Telescopic
Hook stroke 1100mm
Sprung suspension capacity 21000kg
Main cylinders 2 units
Oil requirement 20 litres
Minimum draft requirement 120HP
Hydraulic pressure required 200 bar
Total length 7500mm
Maximum width (standard wheels) 2550mm
Standard wheels 560/45 R22,5
Connections to tractor 3 x double acting
Standard SS 3021

All weights and measurements are subject to hook lift system specification and regional laws. Specification, weights and payload may vary on fast tow models.As we are continually improving our products, technical details, masses and measurements are given as reference values only.
