Model | DumpLoada DL600 |
---|---|
Gross weight | 18000kg |
Tare weight | ca. 3500kg |
Maximum Payload | 14500kg |
Drawbar load | 3000kg (4000kg*) |
Sprung suspension capacity | 14000kg |
Standard transport capacity | 6m³ |
Lift capacity of step 1 at 180 bar | 29,7 tonnes |
Oil requirement | 15,5 litres |
Minimum draft requirement | 100HP |
Hitch height | 510-550-590mm |
Bottom tickness | 6mm HARDOX 450 |
Side tickness | 6mm HARDOX 450 |
Body height inside | 600mm |
Body length inside | 4060mm |
Total length | 5605mm |
Total height | 1785mm |
Total height at 65" | - |
Maximum width (standard wheels) | 2550mm |
Standard wheels | 445/40 R22,5 |
Colour | Yellow |
Speed | 40km/h |
All weights and measurements are subject to tipper trailer specification and regional laws. Specification, weights and payload may vary on fast tow models. As we are continually improving our products, technical details, masses and measurements are given as reference values only.
